Socket outlet combination
Productnumber: 73003101 | Dimensions: 315 x 300 x 199 mm
Socket outlet combination, protection class IP44, Extension enclosure, easy combination with STK socket outlet combinations or AK Air small distribution boards with flange openings (AK-F), without flanges
equipped with:
| CEE appliance inlet (on front), 32A, 400V, 5p | 1 |
|---|
| Rated operating voltage AC | 400 V |
|---|---|
| Rated insulation voltage AC | 400 V |
| Protection class | II |
| Type of protection | IP44 |
| vented | yes |
| Number of rows | 0 |
| Number of modules per row | 0 |
| Base unit colour | grey |
|---|---|
| Cover colour | grey |
| Width | 315 mm |
|---|---|
| Length | 300 mm |
| Height | 199 mm |
| Inner width | 295 mm |
| Inner height | 106 mm |
| Weight | 1.7 kg |
| UV-resistant | yes |
|---|---|
| Halogen free | yes |
| Glow-wire flammability according to EN 60695-2-11 | 850 °C |
| Type of fastening | Wall mounting |
|---|---|
| Impact strength | IK08 |
| Sealable | yes |
| Cover screw torque | 1.2 Nm |
| Flange variant | yes |
| max. relative humidity 25°C | 90 % |
|---|---|
| max. relative humidity 40°C | 50 % |
| Min. ambient temperature | -25 °C |
| Max. ambient temperature | 40 °C |
| 24h ambient temperature | 35 °C |
| Installation location | protected outdoor areas |
| EAN | 4013902689842 |
|---|---|
| Packing Unit Code | CT |
| ETIM Class | EC000379 |
| Custom tariff number | 85369095 |
| Base unit material | Polycarbonate, glass-fibre reinforced |
|---|---|
| Cover material | Polycarbonate |
| Sealing material | Polyurethane |
| Cover screw material | Polyamide, glass-fibre reinforced |
| Hinged window material | Polycarbonate |
