Installation housing
Productnumber: 97600801 | Dimensions: 150 x 150 x 106 mm
Installation housing, for site cast or prefabricated concrete structures, for the installation of LV/HV/LED-luminaires and loudspeakers, suitable for adhesive fixing and opposing shuttering, for installation in ceilings from 140 mm, wall installation with IBT support spars, for the installation of VDE-approved lights per DIN EN 60598 (VDE 0711), as well as with F identification or MM identification, protection class IP30, rated insulation voltage: 400V AC, Halogen free
outlet aperture: ø 116 mm
| Rated insulation voltage AC | 400 V |
|---|---|
| Type of protection | IP30 |
| Suitable for | Concrete construction |
| Cover colour | other |
|---|
| Width | 150 mm |
|---|---|
| Length | 150 mm |
| Height | 106 mm |
| Inner height | 80 mm |
| Weight | 0.188 kg |
| Halogen free | yes |
|---|---|
| Flammability class according with UL94 | HB |
| Glow-wire flammability according to EN 60695-2-11 | 650 °C |
| max. relative humidity 25°C | - % |
|---|---|
| max. relative humidity 40°C | 50 % |
| Min. ambient temperature | -25 °C |
| Max. ambient temperature | 40 °C |
| 24h ambient temperature | 35 °C |
| Custom tariff number | 39269097 |
|---|
| Base unit material | Polypropylene |
|---|---|
| Cover material | Polypropylene |
