Terminal block
Productnumber: 89640601 | Dimensions: 23 x 98 x 32 mm
Connecting terminal in accordance with DIN EN 60998 (VDE 0613), Ui=690V. For assembly in junction boxes Abox/Abox Pro from 2024 onwards.
Screw terminal block for Abox/Abox Pro 060, 5-pole - 6 mm², In = 41 A, clampable cross-sections per pole: 4 x 1.5 mm², 4 x 2.5 mm², 4 x 4 mm², 4 x 6 mm² Cu rigid/flexible with wire-end ferrule
| Rated insulation voltage AC | 690 V |
|---|---|
| Rated insulation voltage DC | 690 V |
| Min. conductor cross section | 1,5 mm² |
| Rated current | 41 A |
| Terminal type | Screw terminal |
| Number of poles | 5 |
| shockproof | Yes |
| Connection 1: Strip length | 12 mm |
| Connection 1: Clamping points per pole | 2 |
| Connection 1: Suitable for Cu conductors | 1 |
| Connection 1: Connectable conductor cross-section, single-wire (min) | 1.5 mm² |
| Connection 1: Connectable conductor cross-section, single-wire (max) | 10 mm² |
| Base unit colour | grey |
|---|---|
| Cover colour | grey |
| Width | 23 mm |
|---|---|
| Length | 98 mm |
| Height | 32 mm |
| Weight | 0.076 kg |
| Glow-wire flammability according to EN 60695-2-11 | 960 °C |
|---|
| Connection 1: Tightening moment | 1.2 Nm |
|---|
| EAN | 4013902677276 |
|---|---|
| Packing Unit Code | C62 |
| ETIM Class | EC001284 |
| Custom tariff number | 85369010 |
| Insulating body material | Thermoplastic |
|---|
| CAD-Data | Download 3D-CAD-Data |
|---|
