Mast/pipe fixing set

MABF 65-3

Productnumber: 89601201 | Dimensions: 38 x 65 x 15 mm

Mast/pipe fixing set in stainless steel V2A with fastening screws and quick release clamp for mast/pipe diameters of 60 to 170 mm

for empty enclosure TK 1809, TK 1811, small distribution board AK(i) 05

Colours

Accessory colour other

Dimensions

Width 38 mm
Length 65 mm
Height 15 mm
Weight 0.1488 kg

mechanical properties

Type of fastening Wall/ceiling mounting
Load capacity 10 kg
Torque 2.5 Nm

Ambient conditions

Installation location unprotected outdoor areas

Sales Information

EAN 4013902681426
Packing Unit Code C62
ETIM Class EC002498
Custom tariff number 73079980

Download Data Sheet

Download Data Sheet

Installation instructions

Assembly instruction DE/EN pdf (524 KB)

Dimensioned drawing

Dimensional drawing dwg (128 KB)
Dimensional drawing pdf (128 KB)
Dimensional drawing dxf (460 KB)

Certificate

CE Declaration DE/EN/PL pdf (138 KB)
UKCA Declaration EN pdf (165 KB)
CE Declaration DE/EN/FR pdf (135 KB)

CAD-Data

CAD-Data Download 3D-CAD-Data
